The MA-hs-d series actuators are designed for precise control of motion and torque, resulting in higher accuracy and efficiency. Direct drive actuators are known for their smooth operation, zeroed backlash, and low maintenance requirements, making them ideal for applications where precise positioning and high performance are critical. The actuator features a brushless motor controlled by an MD Series controller with an integrated absolute encoder. The configuration has a hollow shaft, which allows for easier integration in multi-axis setups. Optional extensions include a slip ring for wires.

Parameters:
• Voltage: 12-48 VDC
• Mass: 0.16kg
• Size: 50x76x35mm
• Torque: 0.25/0.5Nm (rated/peak)
• Max speed: 600RPM (max, 16V)
• 14-bit Absolute Encoder
• Daisy chain electrical connectors
• Slip ring for wires as an option
• MD series motor controller: CAN-FD or CANopen Interface

Additional documents:
• 3D model,
• MD series motor controller documentation.

This example demonstrates the actuator configuration, customization is available upon request. Prices for larger quantities are significantly lower and depend on the chosen configuration.
